Reflector Design Software
Key ReflectorCAD Features

  • Import/export of system geometry in IGES format
  • Point-and-click interface for easy graphical creation and aiming of segments
  • Sophisticated engine for accurate and efficient calculation of output gradients
  • Multiple options for visualization of reflector output
  • Includes more than 100 high-quality source models
ReflectorCAD 1.5 (New Version) Highlights
  • Import of IGES base surfaces
  • Positional output
  • Gradient measurement
  • New sources
  • Assigned source points
  • User-defined source points
  • Alternate segment developer
  • Improved built-in base surfaces
  • Easier aim adjustments
  • Updated 3D viewer support
  • Source positions exported to IGES
  • Configuration preferences
  • New Quick Tour
